Parts catalog 7-31
4024-XXX
Assembly 15: High capacity feed (HCF)—covers and media tray
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
15—1 40X0738 1 1 Top cover
2 40X0745 1 3 HCF docking bracket kit
• HCF docking bracket
• HCF docking bracket screw (2)
3 40X0746 1 1 Inner front cover
4 40X0740 2 2 HCF docking latch kit includes:
• HCF docking latch
•Spring
5 40X0739 1 1 Sensor (HCF media tray set)
6 40X0741 4 1 Caster
7 40X0742 1 1 Left cover
8 40X0739 1 1 Sensor (HCF media size L)
9 40X0739 1 1 Sensor (HCF media size R)
10 40X0743 1 1 Rear cover
