Parts catalog 7-47
4024-XXX
Assembly 23: Duplex inner
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
23—1 40X0780 1 1 Duplex unit assembly (this comes assembled)
2 40X0792 1 20 Duplex media transport pinch roll kit includes:
• Duplex media transport pinch roll (10)
• Spring (10)
3 40X0790 1 2 Duplex docking lock (2)
4 40X0791 1 2 Hinge pin (2)
5 40X0793 1 9 Duplex media transport roll kit includes:
• Bushing 6 mm (6)
• Duplex media transport roll (2)
• Duplex media center transport roll
6 40X0789 1 1 Duplex left door support strap
