Parts catalog 7-49
4024-XXX
Assembly 24: Exit 2 outer
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
24—1 40X0794 1 1 Exit 2 unit assembly (this comes assembled)
2 40X0800 1 1 Rear cover
3 40X0797 1 1 Exit 2 left door support strap
4 40X0795 1 2 Exit 2 left door handle kit includes:
• Exit 2 left door handle
•Spring
5 40X0796 1 2 Media diverter gate kit includes:
• Media diverter gate
•Spring
6 40X0798 1 1 Left cover
7 40X0799 1 1 Front cover
