Midas XL8

22 Chapter 2: XL8 Live Performance System Overview
XL8 Control Centre
Operator Manual
I/O units
Router
Monitor
FOH
XL8 Control Centre
Internal bay
processor
Internal router
Internal master
controller
Local I/O units
Mic
splitters
(shared)
DSP
units
This diagram
illustrates an extreme
example of dual
redundancy in a
standard FOH and
stage monitor set up,
where one half of the
system is down.
Please note this is a
highly unlikely
scenario.
Figure 5: System showing 50%
redundancy
Red interconnections
indicate that
communications are
healthy
Greyed out
interconnections
indicate no
communication due
to fault in this side of
system
