UM10462 All information provided in this document is subject to legal disclaimers. © NXP B.V. 2016. All rights reserved.
User manual Rev. 5.5 — 21 December 2016 496 of 523
NXP Semiconductors
UM10462
Chapter 24: LPC11U3x/2x/1x Appendix ARM Cortex-M0
24.5.3.8 SCB usage hints and tips
Ensure software uses aligned 32-bit word size transactions to access all the SCB
registers.
24.5.4 System timer, SysTick
When enabled, the timer counts down from the reload value to zero, reloads (wraps to)
the value in the SYST_RVR on the next clock cycle, then decrements on subsequent
clock cycles. Writing a value of zero to the SYST_RVR disables the counter on the next
wrap. When the counter transitions to zero, the COUNTFLAG status bit is set to 1.
Reading SYST_CSR clears the COUNTFLAG bit to 0.
Writing to the SYST_CVR clears the register and the COUNTFLAG status bit to 0. The
write does not trigger the SysTick exception logic. Reading the register returns its value at
the time it is accessed.
Remark: When the processor is halted for debugging the counter does not decrement.
The system timer registers are:
[1] SysTick calibration value.
24.5.4.1 SysTick Control and Status Register
The SYST_CSR enables the SysTick features. See the register summary in for its
attributes. The bit assignments are:
Table 450. SHPR3 register bit assignments
Bits Name Function
[31:24] PRI_15 Priority of system handler 15, SysTick exception
[23:16] PRI_14 Priority of system handler 14, PendSV
[15:0] - Reserved
Table 451. System timer registers summary
Address Name Type Reset
value
Description
0xE000E010
SYST_CSR RW
0x00000000
Section 24.5.4.1
0xE000E014
SYST_RVR RW Unknown Section 24–24.5.4.2
0xE000E018
SYST_CVR RW Unknown Section 24–24.5.4.3
0xE000E01C
SYST_CALIB RO
0xC0000000
[1]
Section 24–24.5.4.4
Table 452. SYST_CSR bit assignments
Bits Name Function
[31:17] - Reserved.
[16] COUNTFLAG Returns 1 if timer counted to 0 since the last read of this register.
[15:3] - Reserved.
