OKI Data Infotech Corporation CONFIDENTIAL
Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-18
Panel Message
Error Description
User Solution
Service Engineer Inspection
(For inspection criteria, see
Reference to Check/Replace
Parts.)
Assumed
Replacement Part
Reference to
Check/Replace
Parts
The ink system is not
primed.
Restart the printer.
- Install the last firmware version.
- Enter the maintenance mode
and check that INK SYSTEM
STATUS in the SYSTEM menu
is PRIMED.
- Firmware version
- PCB-ASSY-IPB5-100
- EEPROM
<Errors related to the waste ink bottle>
Panel Message
Error Description
User Solution
Service Engineer Inspection
(For inspection criteria, see
Reference to Check/Replace
Parts.)
Assumed
Replacement Part
Reference to
Check/Replace
Parts
No waste ink bottle is
installed.
- Reinstall the waste
ink bottle.
- Restart the printer.
- Check that the MICRO SWITCH
4 (WASTEINK BOTTLE ASSY)
is not missing.
- Check that the MICRO SWITCH
4 connector is connected
correctly.
- In the CHECK SENSORS menu,
select WASTE BOTTLE and
execute INSTALLED, and check
the MICRO SWITCH 4
operation.
- Check that the CN22 connector
on the PCB-ASSY-ACT3 is
connected correctly.
- Check that the connector
between the
CABLE(TU-SENS1)-ASSY(MW)
and the
CABLE(TU-SENS2)-ASSY(MW)
is connected correctly.
- MICRO SWITCH 4
- PCB-ASSY-ACT3
- PCB-ASSY-IPB5-100
- CABLE(TU-SENS1)-
ASSY(MW)
- CABLE(TU-SENS2)-
ASSY(MW)
The waste ink bottle is
full.
- Check the waste
ink inside the
waste ink bottle.
- Reset the waste
ink counter.
- Restart the printer.
Install the last firmware version.
- Firmware version
- PCB-ASSY-IPB5-100
- EEPROM
REPLACE
WASTE INK BOTTLE
INSTALL
WASTE INK BOTTLE
PRIME INK SYSTEM
