Oki IP-6620 - When an error message is displayed

OKI Data Infotech Corporation CONFIDENTIAL
Chapter 5 Troubleshooting (Engine Section and USB Controller Section)
5-76
Error
No.
Cause
User Solution
Service Engineer Inspection
(For inspection criteria, see
Reference to Check/Replace
Parts.)
Assumed Replacement
Part
Reference to
Check/Replace
Parts
3600
Head Heater Error (High
Temperature) (No.1)
- Restart the printer.
- Check the ambient
temperature.
- Check that the ambient
temperature at the installation
location meets the operating
conditions (less than 35 degrees).
- Check that COOLING FAN,MW is
operating in the ACTUATORS
menu.
- Check the connection of COOLING
FAN,MW connectors.
- Check the connection of HEAD
CABLE,MW connectors on the
HCB1M and the print heads.
- Check the connection of
CARRIAGE FFC,MW connectors
on the HCB1M and the IPB5.
- Check the connection of ROBOT
CABLE,MW connectors.
- COOLING FAN,MW
- HEAD CABLE,MW
- INKJET HEAD,MW
- ROBOT CABLE,MW
- CARRIAGE FFC,MW
- PCB-ASSY-HCB1M
- PCB-ASSY-IPB5-100
- ROBOT CABLE,MW
- CARRIAGE FFC,MW
 5.5.58
3601
Head Heater Error (High
Temperature) (No.2)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.58
3602
Head Heater Error (High
Temperature) (No.3)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.58
3603
Head Heater Error (High
Temperature) (No.4)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.58
3604
Head Heater Error (High
Temperature) (No.5)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.58
3605
Head Heater Error (High
Temperature) (No.6)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.58
3606
Head Heater Error (High
Temperature) (No.7)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.58
3610
Head Heater Error (Target
Temperature Not Reached)
(No.1)
- Restart the printer.
- Check the ambient
temperature.
- Check that the ambient
temperature at the installation
location meets the operating
conditions (more than 15 degrees).
- Check the connection of HEAD
CABLE,MW connectors on the
HCB1M and the print heads.
- Check the connection of
CARRIAGE FFC,MW connectors
on the HCB1M and the IPB5.
- Check the connection of ROBOT
CABLE,MW connectors.
- HEAD CABLE,MW
- INKJET HEAD,MW
- ROBOT CABLE,MW
- CARRIAGE FFC,MW
- PCB-ASSY-HCB1M
- PCB-ASSY-IPB5-100
- ROBOT CABLE,MW
- CARRIAGE FFC,MW
 5.5.59
3611
Head Heater Error (Target
Temperature Not Reached)
(No.2)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.59
3612
Head Heater Error (Target
Temperature Not Reached)
(No.3)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.59
3613
Head Heater Error (Target
Temperature Not Reached)
(No.4)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.59
3614
Head Heater Error (Target
Temperature Not Reached)
(No.5)
- Restart the printer.
- Check the ambient
temperature.
- Check that the ambient
temperature at the installation
location meets the operating
conditions (more than 15 degrees).
- Check the connection of HEAD
CABLE,MW connectors on the
HCB1M and the print heads.
- Check the connection of
CARRIAGE FFC,MW connectors
on the HCB1M and the IPB5.
- Check the connection of ROBOT
CABLE,MW connectors.
- HEAD CABLE,MW
- INKJET HEAD,MW
- ROBOT CABLE,MW
- CARRIAGE FFC,MW
- PCB-ASSY-HCB1M
- PCB-ASSY-IPB5-100
- ROBOT CABLE,MW
- CARRIAGE FFC,MW
 5.5.59
3615
Head Heater Error (Target
Temperature Not Reached)
(No.6)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.59
3616
Head Heater Error (Target
Temperature Not Reached)
(No.7)
- Restart the printer.
- Check the ambient
temperature.
ditto
ditto
 5.5.59
