10. Service Mode Field Service Ver. 1.0 Jun. 2008
188
Adjustment / Setting
NOTE
• For details on setting for ACS between [312] and [326], refer to [Setting the soft-
ware switches on ACS].
See P.194
Mode Default value
312
Bit 7654 3210
HEX: 20
State 0010 0000
Bit Setting item
Setting value
Description
01
5-0 Setting printing area for ADF front side lead-
ing edge 1 (A).
Set so that the total with the value in mode
313 bit [5-0] becomes 80mm or under.
000000 0 mm
000001 1 mm
:
100000 32 mm
:
111111 63 mm
Mode Default value
313
Bit 7654 3210
HEX: 07
State 0000 0111
Bit Setting item
Setting value
Description
01
5-0 Setting printing area for ADF front side lead-
ing edge 2 (B).
Set so that the total with the value in mode
312 bit [5-0] becomes 80mm or under.
000000 0 mm
:
000111 7 mm
:
111111 63 mm
Mode Default value
314
Bit 7654 3210
HEX: 21
State 0010 0001
Bit Setting item
Setting value
Description
01
6-0 Setting printing area for ADF front side poste-
rior end 1 (C).
Set so that the value is the same as that in
mode 315 bit [6-0] or over.
0000000 0 mm
0000001 1 mm
:
0100001 33 mm
:
1000010 66 mm
others Not available
