Paper Feed Unit PB1170(D3GQ-17)
D0CA/D0C9/D0C8/D0CB 2-60 SM
2.11 PAPER FEED UNIT PB1170(D3GQ-17)
2.11.1 ACCESSORY CHECK
Confirm that you have the accessories listed below.
No. Description Q’ty
- EMC Address 1
- Name Plate 1
- Decal Paper Size/ Tray Number 1
- Decal CHN 10mm 1
- Decal CHN Date 40mm 1
A Joint bracket (Front left) 1
B Joint bracket (Front right) 1
C Joint bracket (Front center) 1
D Joint bracket (Frame) 1
E Joint bracket (Rear) 1
- Screw M3x6 7
- Screw M3x8 3
- Screw M3x12 1
• The supplied brackets [A] to [E] and screws are used when installing the
dehumidification heater. Refer to "Dehumidification Heater (PFU)" for how to install
the dehumidification heater.
