1-Bin Tray BN1040 (D574-59)
SM 2-75 D0CA/D0C9/D0C8/D0CB
2.13.2 INSTALLATION PROCEDURE
• Turn OFF the main power and unplug the power cord from the wall socket. If the main
power is not turned OFF before installing, an electric shock or malfunction might occur.
Remove the left upper cover [A] .
1. Remove the rear cover [A].
2. Open the right cover, and then remove the right rear cover [A] .
To Next Page
