Paper Feed Unit PB1170(D3GQ-17)
SM 2-61 D0CA/D0C9/D0C8/D0CB
2.11.2 INSTALLATION PROCEDURE
• Turn OFF the main power and unplug the power cord from the wall socket. If the main
power is not turned OFF before installing, an electric shock or malfunction might occur.
• Lifting the mainframe requires two or more people. The mainframe is highly unstable
when lifted by one person and could cause injury or property damage.
• Do not lift the machine with any optional paper feed units attached.
If the machine already has one or more optional paper feed unit(s) attached, be sure to
disconnect the machine and paper feed unit(s), and lift them up separately when
moving/transporting. Otherwise, the handle of the paper feed unit will break due to the
mainframe’s weight, and it can cause an injury.
• Be sure to hold the following positions when lifting the mainframe.
1. Remove the packaging tapes and the sheet (EMC address) on the paper feed unit.
2. Slowly place the main machine on the paper feed unit.
• When installing the second paper feed unit, place it on the first paper feed unit.
Then place the main machine on the pair of paper feed units.
