Firmware Update (Removable Media)
SM 5-5 D0CA/D0C9/D0C8/D0CB
Maintenance
5.3 FIRMWARE UPDATE (REMOVABLE MEDIA)
5.3.1 OVERVIEW
• Removable media (SD card or USB flash drive) are a precision device, so when you
handle them, respect the following.
• When the power is switched ON, do not insert or remove the removable media.
• During installation, do not switch the power OFF.
• Since the removable media is manufactured to high precision, do not store it in a hot or
humid location, or in direct sunlight.
• Do not bend the removable media, scratch it, or give it a strong shock.
• Before downloading firmware to an SD card, check whether write-protection of the SD
card is disabled. If write-protection is enabled, an error code (error code 44, etc.) will
be displayed during download, and the download will fail.
• Before updating the firmware, remove the network cable from this machine.
• During software update, disconnect network cables and interface cables, remove
wireless boards, etc., (so that they are not accessed during the update).
5.3.2 MEDIA SLOT TO USE WHEN UPDATING
Using the SD card
Use SD Card Slot 2 [A: Lower Slot] on the back of the machine or the SD card slot [B] on the left
side of the operation panel.
• When inserting into the slot, push the SD card until it clicks.
• Check whether the card is properly in the SD card slot. When an SD card is inserted, a
click is heard, and it is locked.
• To remove the card, release by pressing once.
To use the SD card slot [A], remove the SD card slot cover [C] in the
figure below.
