Image Adjustment
SM 4-263 D0CA/D0C9/D0C8/D0CB
&
Adjustment
is as follows:
1. Turn ON the power and enter the SP mode.
2. Select "System SP."
3. Execute MUSIC (SP2-111-004).
4. Check the result for each color with the following SPs.
• SP2-117-004 (K)
• SP2-117-002 (C)
• SP2-117-001 (M)
• SP2-117-003 (Y)
• If all of the SP values are within ±5, go to Step 9.
• If any of the SP values are not within ±5, go to Step 5.
Remove the paper exit tray [A]
1. Close the front door.
2. Rotate the knob(s) shown in the photo [A] to [D] at 90 degree intervals until the SP value for
the affected color(s) is 0.
• There are two knobs on each of the two LD units. A click is felt every 90 degree
rotation.
• Turning the knob clockwise by 90 degrees changes the SP value by -1.
To Next Page
