SC2xx: Exposure
D0CA/D0C9/D0C8/D0CB 6-20 SM
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC285-00 C MUSIC Error
The results of MUSIC pattern reading failed 4 times.
The ID sensors (S27-S29) cannot detect the MUSIC pattern
Color registration error is larger than the specified value
Refer to "When SC285-00 (MUSIC error) Is Displayed"
6.3.1 WHEN SC285-00 (MUSIC ERROR) IS DISPLAYED
As SC285-00 is a logging SC (SC Type C), it is not displayed at once when an error occurs.
Though the equipment can be operated, check the SC history and perform a recovery operation
if the SC has occurred.
