Ricoh IM C400F

Paper Feed and Registration (New Functions)
SM 7-91 D0CA/D0C9/D0C8/D0CB
Detailed
Descriptions
7.14 PAPER FEED AND REGISTRATION (NEW
FUNCTIONS)
The actual paper length is measured by the registration sensor (S32) and compared with
the paper length configured in the machine's Paper Tray Settings. If there is a difference
of 30 mm or more, an internal flag is set to indicate a paper length error.
If paper jams while this flag is set, a message reporting a paper configuration error and
explaining the correct way to configure the paper setting appears on the operation panel. This
reduces paper jams due to misconfiguration by the user.
You can specify whether or not to display the guidance and check the occurrence count with the
following SP.
Function SP No.
Displaying Guidance SP1-010-001 (Size Set Miss Detection Mode:
Paper Length Detection)
0: OFF
1: ON
Paper Length Error Detection Count: Tray 1 SP1-011-001 (Size Set Miss Detection Count: Papr
Lngth Dtct:F1)
Paper Length Error Detection Count:
Bypass Tray
SP1-011-002 (Size Set Miss Detection Count: Papr
Lngth Dtct:MF)
Paper Length Error Detection Count: Tray 2
(Optional PFU1)
SP1-011-003 (Size Set Miss Detection Count: Papr
Lngth Dtct:F2)
Paper Length Error Detection Count: Tray 3
(Optional PFU2)
SP1-011-004 (Size Set Miss Detection Count: Papr
Lngth Dtct:F3)
Paper Length Error Detection Count: Tray 4
(Optional PFU3)
SP1-011-005 (Size Set Miss Detection Count: Papr
Lngth Dtct:F4)
If the image fails to be transferred to the paper in time after the paper reaches the
registration point, it is possible to continue printing by forming the image again
(resending the image). This reduces the paper jam (JAM10, 15, 16, 17) (failing to slacken
the paper for skew adjustment on the registration roller).
You can specify whether or not to resend the image with the following SPs. (The default setting
of each is "ON".)
0: OFF
1: ON
