Ricoh IM C400F User Manual

SC2xx: Exposure
SM 6-15 D0CA/D0C9/D0C8/D0CB
Troubleshooting
6.3 SC2XX: EXPOSURE
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC202-01 D Polygon Motor Error 0: ON Timeout: K, C
SC202-03 D Polygon Motor Error 1: ON Timeout: M, Y
Polygon Mirror Motor (M5,M6) cannot rotate correctly.
This SC is detected when the Polygon Mirror Motor (M5,M6) starts rotating, or
its rotating speed is changed.
• Polygon Mirror Motor failure
• Motor drive error
• Polygon Mirror Motor harness is defective, disconnected, or
short-circuited
• BiCU failure (Incorrect polygon motor control signal, damaged Laser
ASIC)
• Defective PSU (PCB16)(PCB17) or power supply part for polygon motor
• Incorrect AC voltage
1. Cycle the power OFF/ON.
2. Check the harness between Laser unit and BiCU (PCB1).
3. Check CN300 (a connector with three pins) for the Polygon Mirror Motor
(M5,M6) from the PSU (PCB16)(PCB17).
There is no problem if the multimeter indicates 24±2V.
4. Replace the Laser unit (Polygon Mirror Motor (M5,M6)).
5. Replace the harness between the Laser unit and BiCU (PCB1).
6. Replace the BiCU (PCB1).
7. Replace the PSU (PCB16)(PCB17).
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC203-01 D Polygon Motor Error 0: OFF Timeout: K, C
SC203-03 D Polygon Motor Error 1: OFF Timeout: M, Y
Polygon Mirror Motor (M5,M6) cannot stop correctly.
This SC is detected when the Polygon Mirror Motor (M5,M6) is deactivated.
• Polygon Mirror Motor failure
• Motor drive error
• Polygon Mirror Motor harness is defective, disconnected, or
short-circuited
• BiCU failure (Incorrect polygon motor control signal, damaged Laser
ASIC)
• Defective PSU (PCB16)(PCB17) or power supply part for Polygon Motor

Ricoh IM C400F Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.2 s
Time to first page (color, normal)	7.4 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Paper tray media types	Bond paper, Card stock, Coated paper, Envelopes, Labels, Letterhead, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Total input capacity	550 sheets
Total output capacity	200 sheets
Maximum input capacity	2300 sheets
Total number of input trays	2
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Print, Scan
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	PCL 5, PCL 6, PDF, PostScript 3
Modem speed	33.6 Kbit/s
Fax transmission speed	2 sec/page
USB connector	USB Type-A / USB Type-B
Optional connectivity	Wireless LAN
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP
Internal memory	2048 MB
Compatible memory cards	SD
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Control type	Touch
Product color	Black, White
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1350 W
Power consumption (ready)	60.7 W
Power consumption (average operating)	- W
Energy Star Typical Electricity Consumption (TEC)	0.48 kWh/week
Scan to	E-mail, FTP, Memory Card, Network folder, USB
Scanner type	Flatbed & ADF scanner
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista

Weight and Dimensions

Depth	561 mm
Width	498 mm
Height	590 mm
Weight	50000 g
