Ricoh IM C400F

Mechanism
D0CA/D0C9/D0C8/D0CB 8-10 SM
8.2 MECHANISM
8.2.1 SYSTEM COMPONENTS
Hardware Specifications
No. Name No. Name
1 Speaker 9 Microphone
2 Main power indicator 10 Extended Feature key (EX3)
3 USB slot for digital cameras 11 Extended Feature key (EX2)
4 USB slot for NFC card readers 12 Extended Feature key (EX1)
5 NFC tag 13 Control panel reboot key
6 [Check Status] indicator 14 SD card slot
7 Data In indicator (facsimile and printer modes) 15 Media access lamp
8 Fax indicator 16 USB slot
Category Specification
LCD panel
• Size
10.1 inch panel
• Resolution
WSVGA (1024x600)
• Bit width
RGB666 (18 bit color)
• Brightness
250cd/m
2
(typ.)
• Backlight
LED Backlight (life: 15,000 hours)
