Ricoh IM C400F

Special Tool s
SM 4-19 D0CA/D0C9/D0C8/D0CB
Replacement
&
Adjustment
• Vertical Transport Gear 01
• Vertical Transport Gear 02
Scanner: Scanner Motor: Gear
Timing Belt Gear [A]
• Reduction Gear [B]
Lubrication parts Lubrication spots
2 gears 5 spots
