Electrical Components
D0CA/D0C9/D0C8/D0CB 4-210 SM
4.19.2 HDD
• Before replacing the HDD, copy the address book data to an SD card with
SP5-846-051 if there is no problem.
• If the customer uses the Data Overwrite Security, IC card reader, or OCR unit, these
applications must be installed again after replacing the HDD.
1. Remove the following parts.
• Rear Cover
• Upper Left Cover
• Left Cover
2. Remove the HDD with the bracket [A].
3. Remove the bracket from the HDD [A].
To Next Page
