Ricoh IM C400F

Controller Options
SM 2-145 D0CA/D0C9/D0C8/D0CB
Installation
operation panel.
Press "Restore Factory Defaults" to initialize the following settings:
• Transmission mode
• Channel
• WEP
• SSID
• WEP Key
SP Mode and UP Mode Settings for IEEE 802.11a/g/n
The following SP commands and UP modes can be set for IEEE 802.11a/g/n:
SP No. Name Function
SP5-840-011 WEP Key
Select
Used to select the WEP key (Default: 00).
UP mode Name Function
SSID Used to confirm the current SSID setting.
WEP Key Used to confirm the current WEP key setting.
WEP Mode Used to show the maximum length of the string that can be used
for the WEP Key entry.
2.20.5 DEVICE SERVER OPTION TYPE M37 (D3GF-10, -11)
Component Check
No Items Q’ty Remarks
1 Cable Ties 2
2 Interface Board 1
3 Ferrite Core 2
