SD Card Options
D0CA/D0C9/D0C8/D0CB 2-170 SM
2.21.6 XPS DIRECT PRINT OPTION TYPE M41 (D0CJ-02, -20)
Component Check
No. Description Q'ty Remarks
1 XPS Direct Print SD Card 1
Installation Procedure
• Turn OFF the main power and unplug the power cord from the wall socket. If the main
power is not turned OFF before installing, an electric shock or malfunction might occur.
1. Remove the SD card slot cover [A].
2. Insert the SD card (XPS) in SD slot 1 (upper) with its label face to the front of the machine.
Merge the SD card contents if necessary. (SD Card Appli Move)
3. Turn ON the power.
4. Attach the SD card slot cover.
5. Make sure that the machine can recognize the option. (see Check All Connections at the
end of this section)
