NVRAM Data Upload/Download
D0CA/D0C9/D0C8/D0CB 5-44 SM
5.9 NVRAM DATA UPLOAD/DOWNLOAD
5.9.1 UPLOADING CONTENT OF NVRAM TO AN SD CARD
Do the following procedure to upload SP code settings from NVRAM to an SD card.
• This data should always be uploaded to an SD card before the NVRAM is replaced.
• Make sure that the write protection of an SD card is unlocked.
1. Do SP5-990-001 (SP Print Mode: All(Data List)) before you turn the machine off. You will
need a record of the NVRAM settings if the upload fails.
Make sure to shut down and reboot the machine once before printing the SMC. Otherwise,
the latest settings may not be collected when the SMC is printed.
2. Turn OFF the power.
3. Remove the SD slot cover [A].
4. Insert the SD card into SD card slot 2 (lower) [A].
5. Turn ON the power.
6. Do SP5-824-001 (NVRAM Data Upload) and then press [Execute].
7. The following files are coped to an NVRAM folder on the SD card when the upload
procedure is finished. The file is saved to the path and the following filename:
NVRAM\<serial number>.NV
Here is an example with Serial Number "K5000017114":
NVRAM\K5000017114.NV
