Service Program Mode
SM Appendices
3-3 D0CA/D0C9/D0C8/D0CB
SP Mode Tables
SP Mode Button Summary
Here is a short summary of the touch-panel buttons.
1 Opens all SP groups and sublevels.
2 Closes all open groups and sublevels and restores the initial SP mode display.
3 Opens the copy window (copy mode) so you can make test copies. Press SP Mode
(highlighted) in the copy window to return to the SP mode screen,
4
Enter the SP code directly with the number keys if you know the SP number. Then press
.
(The required SP Mode number will be highlighted when pressing
. If not, just press the
required SP Mode number.)
5 Press two times to leave the SP mode and return to the copy window to resume normal
operation.
6 Press any Class 1 number to open a list of Class 2 SP modes.
