Ricoh IM C400F

Process Control Error Conditions
D0CA/D0C9/D0C8/D0CB 6-130 SM
6.11.2 LINE POSITION ADJUSTMENT RESULT
SP2-194-010 to -012 (Line Position Adjustment Result: M, C, Y)
This SP shows the number as a line position adjustment result on the LCD. It shows which color
has an error (M, Y or C).
No. Result Description Note
0 Not done Line position adjustment has not been done. -
1 Completed
successfully
Line position adjustment has correctly been done, -
2 Cannot detect patterns ID sensors (S27-S29) have not detected the patterns for
line position adjustment.
See
Note
3 Fewer lines on the
pattern than the target
The patterns, which ID sensors (S27-S29) have detected,
are not enough for line position adjustment.
See
Note
4 More lines on the
pattern than the target
Not used in this machine. -
5 Out of the adjustment
range
ID sensors (S27-S29) have correctly detected the
patterns for line position adjustment, but a shift of
patterns is out of adjustable range.
See
Note
6-9 Not used - -
• For details, see the "Line Position Adjustment" section.
