Special Tool s
SM 4-13 D0CA/D0C9/D0C8/D0CB
&
Adjustment
• Transport Gear 04 [D]
• Registration Clutch (CL8) [E]
Drive: Transport Drive Unit: IM C400 series
Description Description
[A] Transport Gear 01 [E] Transport Gear 05
[B] Transport Gear 02 [F] Vertical Transport Gear 01
[C] Transport Gear 03 [G] Vertical Transport Gear 02
[D] Transport Gear 04
Transport Drive Bracket
Lubrication parts Lubrication spots
6 studs 6 spots
