Input and Output Check
SM Appendices
3-445 D0CA/D0C9/D0C8/D0CB
SP Mode Tables
No. Part Name SP Name SP No. Reading
0 1
9 Tray Lower Limit
Sensor (S39)
Tray Overflow SN 6-145-009 Paper not
detected
Paper
detected
10 - Staple HP
Sensor*1
6-145-010 - -
11 - Staple Near End
SN*1
6-145-011 - -
12 - Self Priming
Sensor*1
6-145-012 - -
13 Interlock switch Front Door SW 6-145-013 Front door
closed
Front door
open
*1 These SPs are not used in this machine.
OUTPUT Check
No. Part Name SP Name SP No. Remarks
14 Paper transport motor (M16) Transport Motor 6-146-001
15 Paper exit motor (M17) Paper Ext Motor 6-146-002
16 Jogger motor (M20) Jogger Motor 6-146-003
17 Shift roller motor (M19) Shift Roller Motor 6-146-004
18 Gathering roller motor (M18) Positioning Motor 6-146-005
19 Exit guide plate motor (M21) Ext Guide Plate Motor 6-146-006
20 Tray lift motor (M22) Tray Lift Motor 6-146-007
21 Staple motor (M23) Stapler Motor 6-146-008
22 Stopper Solenoid (SOL3) Paper Height SOL 6-146-009
3.13.4 PAPER FEED
