Paper Exit: Paper Exit Drive Unit
Studs
Lubrication parts Lubrication spots
4 studs 6 spots
Description Description
[A] Paper Exit Drive Unit Stud 01 [C] Paper Exit Drive Unit Stud 03
[B] Paper Exit Drive Unit Stud 02 [D] Paper Exit Drive Unit Stud 04
• Gears
Lubrication parts Lubrication spots
9 gears 12 spots
