SM 4-23 D0CA/D0C9/D0C8/D0CB
&
Adjustment
Description Description
[A] Paper Exit Drive Gear 01 [E] Paper Exit Idler Gear 02
[B] Paper Exit Drive Gear 02 [F] Paper Exit Idler Gear 03
[C] Paper Exit Drive Gear 03 [G] Paper Exit Idler Gear 04
[D] Paper Exit Idler Gear 01
• Paper Exit Unit Guide
Lubrication parts Lubrication spots
1 guide 1 spots
