Ricoh IM C400F

Replacement and Adjustment
D0CA/D0C9/D0C8/D0CB 8-8 SM
8.1.5 MICROPHONE
1. Remove the operation panel unit. (Operation Panel)
2. Remove the main controller board (Main Controller Board).
3. Remove the LCD unit (LCD).
4. Remove the microphone [A].
8.1.6 NFC BOARD
1. Remove the operation panel unit. (Operation Panel)
2. Remove the hinge cover [A].
3. Remove the cover of the NFC board [A].
