Exterior Covers
D0CA/D0C9/D0C8/D0CB 4-44 SM
4.4.9 REAR BOTTOM COVER
This procedure is for IM C400SRF.
1. Remove the rear bottom cover[A].
4.4.10 RIGHT BOTTOM COVER
These procedures are for IM C400SRF.
1. Remove the front lower cover.
2. Remove the right rear cover.(Right Rear Cover)
3. Remove the right bottom cover[A].
