Ricoh IM C400F

Maintenance Tables
D0CA/D0C9/D0C8/D0CB 2-4 SM Appendices
Others
The PM count for the following items is based on the sheets of copy paper fed:
Item PM/Yield
Parts
90k EM Remarks
Waste toner
bottle
P R Replace if the waste toner bottle is detected to
be full.
Ozone filter C
Paper Feed Unit (Optional)
The PM count for the following items is based on the sheets of copy paper fed:
Item PM/Yield Parts 120k EM Remarks
Paper feed roller Y R C Wipe with a damp cloth.
Friction pad Y R C Wipe with a damp cloth.
Transport roller C Wipe with a damp cloth.
Tray lift pad C Wipe with a damp cloth.
Transport sensor (S1) C Wipe with a damp cloth.
1-Bin Tray Unit (Optional)
Item PM/Yield
Parts
EM Remarks
Paper exit roller C Wipe with a damp cloth, and then wipe the
dry cloth.
Paper exit tray C Wipe with a damp cloth, and then wipe the
dry cloth.
1-bin tray exit sensor C Clean with a blower brush or wipe with a
dry cloth.
1-bin tray paper remaining
sensor
C Clean with a blower brush or wipe with a
dry cloth.
2.1.2 PREVENTIVE MAINTENANCE ITEMS FOR IM C400 SERIES
duplex entrance sensorChart: A4 (LT)/5%
Mode: 2 prints/job
Color Ratio: 30%
Environment: Normal temperature and humidity
Yield may change depending on circumstances and print conditions.
Symbol keys: C: Clean, R: Replace, L: Lubricant, I: Inspect
Yield Parts:
