SP4-XXX (Scanner)
SM Appendices
3-179 D0CA/D0C9/D0C8/D0CB
SP Mode Tables
3.6 SP4-XXX (SCANNER)
SP No. Large Category Small Category ENG or
CTL
[Min to Max/Init./Step]
4-008-001 Sub Scan
Magnification Adj.
ENG* [-1.0 to 1.0 / 0.0 /
0.1%/step]
4-010-001 Sub Scan
Registration Adj.
ENG* [-1.0 to 1.0 / 0.0 /
0.1mm/step]
4-011-001 Main Scan
Registration Adj.
ENG* [-2.0 to 2.0 / 0.0 /
0.1mm/step]
4-012-001 Scanner Erase
Margin: Scale
Book: Sub Scan Leading
Edge (Left)
ENG* [0.0 to 3.0 / 1.0 /
0.1mm/step]
4-012-002 Scanner Erase
Margin: Scale
Book: Sub Scan Trailing
Edge (Right)
ENG* [0.0 to 3.0 / 1.0 /
0.1mm/step]
4-012-003 Scanner Erase
Margin: Scale
Book: Main Scan
Leading Edge (Rear)
ENG* [0.0 to 3.0 / 1.0 /
0.1mm/step]
4-012-004 Scanner Erase
Margin: Scale
Book: Main Scan Trailing
Edge (Front)
ENG* [0.0 to 3.0 / 1.0 /
0.1mm/step]
4-013-001 Scanner Free Run Lamp OFF ENG [0 to 1 / 0 / 1/step]
4-013-002 Scanner Free Run Lamp ON ENG [0 to 1 / 0 / 1/step]
4-014-001 Scan HP Detection Enable ENG [0 to 1 / 0 / 1/step]
4-014-002 Scan HP Detection Disable ENG [0 to 1 / 0 / 1/step]
4-014-003 Scan HP Detec. On (FC
600dpi LG)
ENG [0 to 1 / 0 / 1/step]
4-014-004 Scan HP Detec. On (BW
600dpi LG)
ENG [0 to 1 / 0 / 1/step]
4-014-005 Scan HP Detec. On (FC
1200dpi LG)
ENG [0 to 1 / 0 / 1/step]
4-016-001 DF Scan FC 600 x 300dpi Duplex
Mode
ENG [0 to 1 / 0 / 1STEP/step]
4-016-002 DF Scan Bk 600 x 300dpi Duplex
Mode
ENG [0 to 1 / 0 / 1STEP/step]
4-016-003 DF Scan FC 600 x 600dpi Duplex
Mode
ENG [0 to 1 / 0 / 1STEP/step]
4-016-004 DF Scan Bk 600 x 600dpi Duplex
Mode
ENG [0 to 1 / 0 / 1STEP/step]
4-016-005 DF Scan Bk 600 x 200dpi Duplex
Mode
ENG [0 to 1 / 0 / 1STEP/step]
