Caster Table Type M41 (D3GW03)
D0CA/D0C9/D0C8/D0CB 2-72 SM
11. Secure the 1st and 2nd levels of the optional paper feed unit and the main machine with
the four joint brackets [A].
Use the screws [B] on the main machine.
Installing the caster table, optional paper feed unit (3nd level), and main machine
Follow the same procedure when installing the 3rd level of the optional paper feed
unit.When you do this, secure the 1st, 2nd, and 3rd levels of the optional paper feed unit
and the main machine with six joint brackets [A].
12. Reattach the rear covers of the optional paper feed units.
