SP4-XXX (Scanner)
SM Appendices
3-189 D0CA/D0C9/D0C8/D0CB
SP Mode Tables
SP No. Large Category Small Category ENG or
CTL
[Min to Max/Init./Step]
R 1digit/step]
4-713-001 CIS GB Adj. Value:
G
ENG* [-384 to 255 / -76 /
1digit/step]
4-714-001 CIS GB Adj. Value:
B
ENG* [-384 to 255 / -85 /
1digit/step]
4-723-001 OUTPUT Check Scanner Lamp: Color ENG [0 to 1 / 0 / 1/step]
4-745-001 CIS Scan Adjust
Error
White level ENG [0 to 65535 / 0 / 1/step]
4-745-002 CIS Scan Adjust
Error
Black level ENG [0 to 65535 / 0 / 1/step]
4-746-001 CIS GB Adj Error
Flag
ENG [0 to 7 / 0 / 1/step]
4-747-001 CIS Scanner Hard
Error
Power-ON ENG [0 to 65535 / 0 / 1/step]
4-785-001 CIS White Level
Peak Target
Color ENG* [0 to 1024 / 707 /
1digit/step]
4-796-001 Low Density Color
Correction
Front Side ENG* [0 to 3 / 0 / 1/step]
0: OFF
1: WEAK
2: MEDIUM
3: STRONG
4-796-002 Low Density Color
Correction
Rear Side ENG* [0 to 3 / 0 / 1/step]
0: OFF
1: WEAK
2: MEDIUM
3: STRONG
4-797-001 Rear Side: Digital
AE
Low Limit Setting ENG [0 to 1023 / 364 / 1/step]
4-797-002 Rear Side: Digital
AE
Background Erase Level ENG [512 to 1535 / 932 /
1/step]
4-799-001 CIS Test Pattern
Change
ENG [0 to 255 / 0 / 1/step]
4-802-001 DF Shading
FreeRun
Lamp OFF ENG [0 to 1 / 0 / 1/step]
4-802-002 DF Shading
FreeRun
Lamp ON ENG [0 to 1 / 0 / 1/step]
4-803-001 Home Position Adj. ENG* [-1.5 to 1.0 / 0.0 /
