Printer Service Mode
SM Appendices
3-425 D0CA/D0C9/D0C8/D0CB
SP Mode Tables
1001 Bit Switch
- Spool printing (WIM >Configuration > Device Settings > System)
- Printing a large number of jobs continuously (The status of the job are not acquired
when jobs exceeding the number guaranteed by the job monitor are continuously
printed.)
bit
3
DFU - -
bit
4
Timing of the PJL Status ReadBack (JOB END)
when printing multiple collated copies.
Mode 0 Mode 1
This BitSw determines the timing of the PJL STATUS JOB END sent when multiple
collated copies are being printed.
Mode 0: JOB END is sent by the device to the client after the first copy has
completed printing. This causes the page counter to be incremented after the first
copy and then again at the end of the job.
Mode 1: JOB END is sent by the device to the client after the last copy has finished
printing. This causes the page counter to be incremented at the end of each job.
bit
5
UTF-8 Mode Enabled Disabled
Enabled (=0):
Text composed of UTF-8 characters can be displayed in the operation panel.
Disabled (=1):
UTF-8 characters cannot be displayed in the operation panel.
For example, job names are sometimes stored in the MIB using UTF-8 encoded
characters. When these are displayed on the operation panel, they will be garbled
unless this BitSw is enabled (=0).
bit
6
Print Option Configuration (rsh, rcp, ftp) Enabled Disable
This BitSw enables the specification of the configuration of the print option using
rcp/rsh/ftp.
bit
7
Enable/Disable Print from USB/SD's Preview
function
Enabled Disabled
Determines whether the Print from USB/SD function will have the Preview function.
Enabled (=0): Print from USB/SD will have the Preview function.
Disabled (=1): Print from USB/SD will not have the Preview function.
1001 Bit Switch
010
Bit Switch A 0 1
bit 0
to 3
DFU - -
bit 4 Not Used - -
bit 5 Store and Skip Errored Job locks the queue Queue is not Queue locked
