Input and Output Check
SM Appendices
3-455 D0CA/D0C9/D0C8/D0CB
SP Mode Tables
No. Part Name SP Name SP No. Reading
0 1
4 Drum motor (CMY) (M10) FC Drum Motor: Lock 5-803-040 Lock Normal
5 Drum motor (M11) Bk Drum Motor: Lock 5-803-038 Lock Normal
Output Check
No. Part Name SP Name SP No. Remark
1 Fusing
motor (M13)
Fusing Motor:
Standard
Speed 1
5-804-029 Do not use these SPs, but use following
SPs instead.
• SP1-158-001 (Abnormal Noise
Confirmation: Unit: Execute)
• SP1-158-002 (Abnormal Noise
Confirmation: No Unit: Execute)
A simple heater control is performed in
these SPs, and temperature rises
excessively. It can cause the fusing sleeve
damaged.
Fusing Motor:
Low Speed
5-804-030
Fusing Motor:
Standard
Speed 2
5-804-091
Fusing Motor:
Middle Speed
5-804-096
2 Paper
transport
motor (M12)
Transport
Motor: Std
Speed 1
5-804-031
Transport
Motor: Low
Speed
5-804-032
Transport
Motor:
Standard
Speed 2
5-804-092
Transport
Motor: Middle
Speed
5-804-097
3 Development
motor
(CMY) (M9)
FC Dev Motor:
Std Speed 1
5-804-024
FC Dev Motor:
Low Speed
5-804-025
FC Dev Motor:
Middle Speed
5-804-094
4 Drum motor
(CMY) (M10)
FC Drum
Motor: Std
Speed 1
5-804-027 When you turn ON the motor with these
SPs, make sure to separate the color drums
and ITB.
To Next Page
