Ricoh IM C400F

Bypass
D0CA/D0C9/D0C8/D0CB 4-184 SM
5. Remove the bearing (bearing × 1)
6. Remove the E-ring at the front of the bypass feed unit ( × 1)
7. Remove the E-ring at the rear of the bypass feed unit ( × 1)
8. Move the front cam and rear cam [B] inward while pushing down the bottom plate [A].
