Image Adjustment
D0CA/D0C9/D0C8/D0CB 4-266 SM
4. Make sure that the front door is closed, and execute execute MUSIC (SP2-111-004).
5. Check the result for each color.
6. Rotate the knob(s) shown in the photo [A] to [D] at 90 degree intervals until the SP value for
the affected color(s) is within ±5 (target: 0).
7. Exit the SP mode.
8. Reattach the paper exit tray.
• Do not touch the LD units while installing the Paper Exit Tray. If the laser units
move, the color skew might have to be adjusted again.
