Installation Requirements
SM 2-5 D0CA/D0C9/D0C8/D0CB
Callout mm (inch) Callout mm (inch)
[J] 505 mm (approx. 19.9") [L] 654 mm (approx. 25.7")
[K] 590 mm (approx. 23.2") [M] 560 mm (approx. 22")
- - [N] 621 mm (approx. 24.4")
- - [O] 706 mm (approx. 27.7")
Callout mm (inch) Note
[A] 1068 mm
(approx.42.0")
IM C400SRF
[B] 1153 mm
(approx. 45.3")
[A] + ADF
[C] 149 mm
(approx. 5.9")
Paper Feed Unit
To Next Page
