Duplex
D0CA/D0C9/D0C8/D0CB 7-98 SM
IM C400SRF
Callout Item Callout Item
[A] Duplex Entrance Sensor (S1) [D] Duplex Exit Sensor (S2)
[B] Duplex Paper Transport Roller
(Upper)
[E] Duplex Paper Transport Roller
(Middle)*1
[C] Duplex Paper Transport Roller
(Lower)
- -
*1 IM C400SRF only
• The IM C400SRF has a longer paper transfer path for duplex printing than other
models, so a Duplex Paper Transport Roller (Middle) is provided.
