Siemens Sinamics G120 Series - p0780[0...1] Value y2 of AO scaling; Value y2:AO scal.; p0781[0...1] Width of AO deadband; AO deadband width; r0785.0...1 CO;BO: Status word of AO; AO stat Wd; p0800[0...2] BI: Download parameter set 0; Dwnl.par.set 0

List of Parameters
Parameters
1-91
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Defines y2 of output characteristic.
Index: [0] = Analog output 0 (AO0)
[1] = Analog output 1 (AO1)
Description: Sets width of dead-band in [mA] for analog output.
Index: [0] = Analog output 0 (AO0)
[1] = Analog output 1 (AO1)
Description: Displays status of analog output.
Bit 0 indicates that the value of analog output 0 is negative.
Bit 1 indicates that the value of analog output 1 is negative.
Description: Defines source of command to start download of parameter set 0 from attached OP.
The first three digits describe the parameter number of the command source, the last digit refers to the bit setting for
that parameter.
Note: Signal of digital input:
0 = No download
1 = Start download parameter set 0 from OP.
p0780[0...1] Value y2 of AO scaling / Value y2:AO scal.
Access level: 2 P-Group: Terminals Data type: Floating Point
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
0 20 20
p0781[0...1] Width of AO deadband / AO deadband width
Access level: 2 P-Group: Terminals Data type: Floating Point
Quick comm. NO Active: NO Data set: -
Can be changed: U, T
Min Max Factory setting
0 20 0
r0785.0...1 CO/BO: Status word of AO / AO stat Wd
Access level: 2 P-Group: Terminals Data type: Unsigned16
Unit: - Data set: -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Analog output 0 negative Yes No -
01 Analog output 1 negative Yes No -
p0800[0...2] BI: Download parameter set 0 / Dwnl.par.set 0
Access level: 3 P-Group: Commands Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: T
Min Max Factory setting
- - 0
