Requirement
WARNING
Risk of injury as a result of foreign bodies in the device
Parts (e.g.: drilling chips, end sleeves) falling into the device can cause short-circuits and
damage the insulation. This can result in severe injury (arcing, loud bang, parts that are ung
out).
• Only perform installation and other work when the devices are current-free.
• Cover the ventilation slots when mounting and installing the control cabinet and remove
the cover before switching on.
NOTICE
Overheating of components due to incorrect mounting position
Incorrectly installed components can overheat during operation. Overheating can lead to
malfunctions and component damage.
• Only install the components in a permissible mounting position in the control cabinet.
The following requirements for installation must be satised:
• Control cabinet panel/mounting panel:
– Housing: Sheet steel
– Panel thickness: 3mm (0.12in)
– Tensile strength: ≥ 270N/mm
2
acc. to DX51 EN10346
• 4 x M6 screws
• 4 x M6 washers
Smart Line Modules
7.11Install the Smart Line Module
Booksize power units
128 Equipment Manual, 09/2023, A5E53307519B AA
