Simrad EK15 User Manual

SimradEK15
bTransceiverinformation
cTransceiverbrowsing
Tip
OntheEK15,theparametersrelatedtotransmissionandtransducerdeptharecontrolled
intheNormalOperationdialogbox.
EachEK15transceiverwithitstransducerand(single)frequencyisreferredtoasa
frequencychannel
.
TheupperpartoftheTransceiverInstallationdialogboxdisplaysalistoffrequency
channelswhicheitherare,orhavebeen,installedontheEK15.Foreachchannelonthe
list,aStatuslabelisprovided.
ThefollowingstatusvaluesareavailableintheTransceiverInstallationdialogbox.
•Busy:Thefrequencychannelisalreadyinuse,probablybyanotherechosounderon
thesamenetwork.Youcannotconnecttothischannel.
•Installed:ThisfrequencychannelisconnectedtoyourEK15system.
•Lost:Thisfrequencychannelcannotbeused.
•Available:Thisfrequencychannelisvacantandreadyforuse.
Note
ItisveryimportantthatyousetuptheEK15tooperatewiththecorrecttransducer(s).
Topics
•TransceiverInstallationdialogbox;Channellistonpage201
•TransceiverInstallation;Transceiverinformationonpage202
•TransceiverInstallation;Transceiverbrowsingonpage203
Relatedprocedures
•Installingafrequencychannelonpage81
•Disconnectingafrequencychannelonpage82
•ModifyingatransceiverIPaddressonpage82
Relatedtopics
•Setupmenu;functionsanddialogsonpage170
•NormalOperationdialogboxonpage154
•Installationmenuonpage189
