Vector VEC-VA Series User Manual

VA Motion Controller Programming Manual
435
when the bit number is
greater than 1, the knife
needs to try to ensure
consistent distance between
the two knives.
SyncAngle
(Synchronous angle)
Range sync area
(peeling angle refers to the
axis)
Unit: degrees
LREA
L
0`360
Exexcute
from FALSE to
TRUE
First_Mark_Offset
(First color distance)
Punctuation color
distance to the cutting
point, this value can be
provided to achieve the
first knife to cut the color
punctuation.
Unit: unit
LREA
L
A positive
number, 0
Exexcute
from FALSE to
TRUE
StartMode
(Startup mode)
Setting the startup
mode of the instruction, as
detailed in the mode
described.
INT
0-4
Exexcute
from FALSE to
TRUE
MasterValueSource
(Spindle
synchronization
source)
Source selection
command from the shaft,
when the selection time
StartMode = 2,3,4,
MasterValueSource must
be 1.
0: Follow the spindle
axis from a position
command
1: the actual position
of the shaft from the
spindle to follow
INT
0,1
Exexcute
from FALSE to
TRUE
BufferMode
(Transfer mode)
Setting the transfer
mode between the two
instructions
0: immediately
interrupted
1: Wait
INT
0,1
Exexcute
from FALSE to
TRUE
Mark_DI_Valid
(Color code
signal valid bit)
Status is TRUE valid
color code signal; FALSE
invalid color code signal;
BOOL
TRUE or
FALSE
Exexcute
from FALSE to
TRUE
Mark_DI_Num
(Punctuation color
signal)
Punctuation terminal
specified color number,
input
INT
0 ~ 15
Exexcute
from FALSE to
TRUE
