VA Motion Controller Programming Manual
451
RatioNumerator
M2
(2 spindle Gear Ratio)
Setting spindle 2 Gear
Ratio
LREAL
Positive or
negative
(Non-default)
Exexcute
from FALSE to
TRUE
RatioDenominator
M2
(2 spindle gear
denominator)
Setting spindle gear
denominator
LREAL
Positive or
negative
(Non-default)
Exexcute
from FALSE to
TRUE
Gear_RatioNumerator
(Electronic gear
molecule)
Molecular electronic
gear ratio MC_GearIn
LREAL
Positive,
negative,
(Non-default)
Exexcute
from FALSE to
TRUE
Gear_RatioDenomina
tor
(Electronic gear
denominator)
Electronic gear
denominator MC_GearIn
LREAL
Positive,
negative,
(Non-default)
Exexcute
from FALSE to
TRUE
Cam_DistanceOffset_
Master
(Spindle position
deviation)
Unit: unit
LREAL
Positive, zero
(0)
Exexcute
from FALSE to
TRUE
Cam_DistanceAdd
(Acceleration
distance)
NS_MC_SpecialCamI
n acceleration distance
sync area reached by a
stationary
LREAL
A positive
number
(Non-default)
Exexcute
from FALSE to
TRUE
Cam_DistanceSync
(Synchronous
distance)
NS_MC_SpecialCamI
n distance synchronous
operation of the sync field
LREAL
Positive, zero
(0)
Exexcute
from FALSE to
TRUE
Cam_DistanceDec
(Deceleration
distance)
NS_MC_SpecialCamI
n deceleration distance
from the sync area reached
stationary
LREAL
A positive
number
(Non-default)
Exexcute
from FALSE to
TRUE
Cam_Pulse_Per_
Unit_M
(Spindle number
of pulses per unit)
This value is
determined according to
MC_SpecialCamIn cam
curve planning, setting this
value such as 5, when the
spindle take 10,000 pulses
at this time that the mobile
terminal of the actuator
spindle position 2000 units.
LREAL
A positive
number
Exexcute
from FALSE to
TRUE
Periodic_Master
_Units
(Spindle cam
means cycles)
Periodic_Master_Unit
s
=
DistanceOffset_Master
+ DistanceAdd *
LREAL
A positive
number
(Non-default)
Exexcute
from FALSE to
TRUE
