3.1.6 NS_CC_CANopen_TPDO(PDO data mapping area
assignment instruction)
FB / FC
Explanation
Applicable model
FB
This command is used to map the data area assigned PDO

Input parameters
name
Features
type of data
Range
setting (default
value)
The
timing of the
entry into force
AXIF_no
(node  
number)
To control
node setting
instruction
WORD
1 to 16
Enable is
TRUE
Enable
(execute bit)
When
Enable is True,
the instruction is
executed
BOOL
TRUE or
FALSE (FALSE)
Enable is
TRUE
Index
(Index)
Data
mapping area
index
WORD
0000 ~ FFFF
Enable is
TRUE
The
DataType (data
type)
type of data
WORD
0000 ~ FFFF
Enable is
TRUE
Data (data
content)
Data content
WORD
0000 ~ FFFF
Enable is
TRUE

Output parameters
name
Features
type of data
Output
range
