Virtex-6 FPGA GTX Transceivers User Guide www.xilinx.com 59

UG366 (v2.5) January 17, 2011

Implementation

X-Ref Target - Figure 1-22

Figure 1-22: Placement Diagram for the FF1759 Package (8 of 9)

LX240T: Not available

LX365T: Not available

LX550T: GTXE1_X0Y7

SX315T: Not available

SX475T: GTXE1_X0Y7

LX240T: Not available

LX365T: Not available

LX550T: GTXE1_X0Y6

SX315T: Not available

SX475T: GTXE1_X0Y6

QUAD_111

LX240T: Not available

LX365T: Not available

LX550T: GTXE1_X0Y5

SX315T: Not available

SX475T: GTXE1_X0Y5

LX240T: Not available

LX365T: Not available

LX550T: GTXE1_X0Y4

SX315T: Not available

SX475T: GTXE1_X0Y4

AP7

AP8

AR1

AR2

AR5

AR6

AT 3

AT 4

AT 8

AT 7

AU10

AU9

AU5

AU6

AU1

AU2

AV7

AV8

AV3

AV4

MGTTXP0_111

MGTTXN0_111

MGTRXP0_111

MGTRXN0_111

MGTTXP1_111

MGTTXN1_111

MGTRXP1_111

MGTRXN1_111

MGTREFCLK0P_111

MGTREFCLK0N_111

MGTREFCLK1P_111

MGTREFCLK1N_111

MGTTXP2_111

MGTTXN2_111

MGTRXP2_111

MGTRXN2_111

MGTTXP3_111

MGTTXN3_111

MGTRXP3_111

MGTRXN3_111

UG366_c1_22_051509
