Pset
102 (428) 9836 3123 01
impact on the calculated mean value and vice versa. A high number of windows make the monitoring
more sensitive; a low number filters more noise.
Graph illustrating PVT selftap
7.8.3 PVT monitoring
In the Pset Programming + branch,
select PVT monitoring.
PVT monitoring is used when the
joint torque has to pass through an
acceptance window prior to P116
Rundown complete in order to pass as
a correct tightening.
Torque
Angle
1. P211 Selftap interval
2. P110 Cycle start
3. P213 Selftap min
4. P214 Selftap max
5. Acceptance window
3.
5.
4.
2.
1.
