Logic Configurator
9836 3123 01 245 (428)
16 Logic Configurator
The Logic Configurator is a tool to combine and configure process signals coming from the
screw tightening process or from an external device. It is available in the Power Focus 4000
hardware only and is programmed over the ToolsTalk PF interface.
The Logic Configurator consists of up to 8 different so called “Configurator sheets”, each denoted with a
number (1 to 8, automatically chosen) and a name (25 positions, editable).
Each Configurator sheet consists of;
inputs, i.e., selectable events from the Relay status array and the DigIn status arrays
instruction list, i.e., logic gate information
output configuration
Every Logic Configurator circuit instruction list is evaluated every 100 ms which corresponds to a tick or
every time an input status changed.
If one digital input is configured several times, on two IO expanders for instance, the DigIn
function status is the OR result of both digital inputs.
The logical events used for input to the Logic Configurator are of the type tracking or
pulse. The pulse type signals are reset after one tick.
Example 1: OK relay is pulsed after an OK tightening and goes low after 100 ms.
Example 2: Reset batch input is pulsed when activated and goes low after 100 ms.
