22.2.2 Multistage programming
Parameter
number
Parameter name
Description
Default
setup
M200
Multistage name
Used when a selected Multistage should be given a name (optional).
M201
Stage list
Stage list specifies the list of available Psets that can be linked together into a
Multistage. Executes the specified link list of Psets into a Multistage.
Pset 1
M202
Batch count
Activates a function that measures how many times a Multistage tightening is
repeated. It must be determined from where the batch size value should be
read, if the batch count is activated.
Options:
Off: batch count is not used.
Pset: use Psets batch size.
Fieldbus: An external source decides batch size via fieldbus.
Ethernet/serial: an external source sets batch size via Ethernet or serial
interface.
If batch count is used in a Job (that includes the specific
Pset), this parameter is recommended to be set to “Off”.
Off
M203
Batch size
Specifies the number of Multistage tightenings in a batch. The range is 0 to
99.
1
M204
Lock at batch OK
The next time batch OK is reached the tool will be disabled until it is
unlocked by the operator.
No
M208
Max coherent
NOK’s
Defines the maximum allowed amount of possible NOK (not OK)
subsequent tightenings. This parameter overrules P153 Max coherent NOK’s.
Off
M210
Torque result
Defines from what stage the torque result will be received.
Accessible when torque is selected as a P100 Control strategy.
Last stage
M211
Angle result
Defines from what stage the angle result will be received.
Accessible when angle is selected as a P100 Control strategy.
Last stage
M212
Rundown result
Defines from what stage the rundown angle result will be received.
Accessible when parameter P104 Rundown angle is used.
Last stage
M213
PVT Selftap result
Defines from what stage the PVT selftap result will be received.
Accessible when P210 Selftap is activated.
Last stage
M214
PVT mon. result
Defines from what stage the PVT mon. result will be received.
Accessible when P220 PVT monitoring is activated.
Last stage
M215
CM result
Defines from what stage the current monitoring result will be received.
Accessible when P200 Current monitoring is activated.
Last stage
M216
Trace
Defines the point from what stage the graph results (Trace diagram) will be
received.
Last stage
M217
Post view torque
result
Defines from what stage the graph will be received.
Accessible when P280 Post view torque is activated.
Last stage
